Bella Luna

Imagine your listening room as an open field. It is late at night. The “Beautiful Moon” shines down upon you as your favorite music plays. These are the Bella Luna omni-directional horn speakers; transporting you to another place, another time and another dimension at your will. These transducers have the complete and total ability to transform your listening space into a live concert venue. The musical signal is reproduced as nature intended. The Bella Luna is in phase in every direction, always; it is perfectly time aligned and has completely natural sonic propagational properties. Natural in terms of the way sound is radiant throughout the atmosphere.

Midrange and high frequencies fire down through the horn system’s bell and is directed throughout space in 360 degrees, while bass notes are fired up and out through the same ingenuous yet simple method. Each corner is a downward firing port, created internally, with special octagonal internal bracing and tuning methods used exclusively in Duevel speakers. Perfect for mid-sized listening spaces, easily powered with SET or higher power amplifiers; let the “Beautiful Moon” light up your nights!

展樂音響 台南音響 經營品牌 Duevel Bella Luna

Die Klaviatur des Hörens

Bella Luna Diamante’s in the “House!”

Bella Luna – History

1997 – 2004
the first version of our Bella Luna.
Professional driver: 22cm woofer and 1” tweeter with kevlar diaphragms
Phase-linear speaker crossover

1998 – 2005
like the 1997 version, visually refined by flattened woofer and base plate and a tweeter ring. Name affix: “diamante”

2005 – 2015
new tweeter with titanium dome and neodymium magnets.
Cable routing to the tweeter through the horn

2015 – 2018
new horn geometry with more elegant shank setting

2018 – today
new woofer with neodymium magnets
new speaker crossover and cabinet tuning

Omnidirectional 2-way Highend Speaker

Woofer
Diameter:22 cm
Neodym magnets
Voice coil:51 mm
Curvilinear, Treated paper Membran
M-roll damped surround
Die cast chassis

Tweeter
Pure Titan cone:44 mm
Neodym magnets:12 x 20 mm
Nomex voice coil former
Patented phase plug design

Phaselinear crossover
Impedance:6 Ohm
Sensitivity:91 dB SPL
Power handling:150 W RMS
Beamwidth ±3dB:40…23kHz
Dimensions
.Width:280mm / 325mm
.Depth:280mm / 325mm
.Height:1050mm
Weight:30 kg
Warranty:5 Years

2023 Price/價格
7.300,00 €
