POWER CABLES | EVO3 INITIUM
GET CONNECTED
EVO3 INITIUM
EVO3 Initium 是 IsoTek 推出的入門級電源線，旨在以親民的價格提供高品質的性能。Initium 是您升級替換標準黑色電源線的絕佳選擇，因為附贈的標準黑色電源線是基於降低成本，而非追求品質。
EVO3 Initium is IsoTek’s entry level power cable designed to offer high quality performance at an extremely fair price. Initium is a must for replacing all of your free standard black plastic power leads which have been designed down to a price not up to a quality.
結構：導線採用平行排列並略帶輕微攪繞的構造。此成熟的技術是抵擋射頻干擾（RFI）與電磁干擾（EMI）的第一道防線。
CONSTRUCTION: The conductors are in a parallel construction with a slight rotational twist. This established technique remains the first line of defence against RFI and EMI rejection.
特 徵
A) 導體：採用 99.9999% 高純度的無氧化銅（OFC）提供了優越的導電性，也較不易隨著時間發生斷裂與劣化。
B) 絕緣體：聚乙烯（PE）化學性質穩定屬強惰性，在廣泛的頻率範圍中擁有極低的介電常數，具有極高的抗壓性、抗裂性和低摩擦係數，為優良的絕緣材料，無論是在耐熱還是絕緣性上，都是安全方面的理想選擇。*
C) 填充物：電源線內部使用棉質填充物，不僅強化線身的結構穩定性，還減緩因震動引起的顫噪效應。棉本身具備優異的絕緣能力，是固體材料中最佳的選擇之一。
D) 包覆層：在上 PVC 外層之前，先以紙質材料包裹以固定結構。紙和棉的添加形成了與 PVC 之間的緩衝層，以保持優異的絕緣特性。
E) 外層護套：使用 PVC 做為外層材料，賦予線身高度的靈活性和韌性。
終端處理：Initium 電源線採用 IsoTek 特製的發燒級 OFC 實心模製接頭，此接頭具有良好的特性（90% 銅 / 10% 鋅 CuZn10 合金，並經過堅固的鎳鍍層處理）。
*澳洲 / 紐西蘭：國別認證原由，規格更改為：導體尺寸 3 x 2.5 平方毫米，絕緣：PVC
FEATURES
A) Conductors: 99.9999% OFC conductors offer an exceptional level of purity with enhanced conductivity. They are less likely to fracture or degrade over time.
B) Dielectric: PE dielectric (insulation) is chemically inert and has a very low dielectric constant over a wide frequency range. PE possesses a very high degree of stress crack resistance and a low coefficient of friction making it an exceptional dielectric. PE is a good choice for safety in both temperature and electrical insulation.*
C) Filler: Cotton filler has been used to give the cable internal strength and reduce microphony. Cotton also possesses excellent dielectric properties, the best of a solid material.
D) Wrap: A paper wrap is used to secure the construction prior to the application of a flexible PVC jacket. The addition of the paper and cotton form a buffer with the PVC so as to maintain exceptional dielectric properties.
E) Jacket: PVC is used as the outer jacket to give a high degree of flexibility and mechanical strength.
TERMINATION: Initium cable is terminated using IsoTek’s bespoke Audiophile grade moulded connectors of solid OFC. These offer good performance qualities (90% copper/10% zinc (CuZn10) with robust nickel plating).
*AUSTRALIA/NEW ZEALAND: DUE TO CERTIFICATION THE FOLLOWING FEATURES HAVE BEEN CHANGED: CONDUCTOR SIZE 3X 1.5SQMM, DIELECTRIC: PVC.
多股6N OFC無氧銅 MULTI 6N OFC AG
正如音響用家期待的，IsoTek 產品達到最高標準的內部佈線，使用純度為 6N OFC（氧化銅 – 99.9999%）導體線，表面鍍銀，提供低電阻和高電流。採用 FEP 導管來保護導體線，同時提供絕佳的內部電力傳輸系統。
IsoTek 的內部佈線與 IsoTek 電源線系列ㄧ起使用可確保持設計和材料特性的共通性。
As one would expect, the internal wiring of any IsoTek product is of the highest standard, pure 6n OFC (Oxygen Free Copper – 99.9999%) conductor strands with silver-plating offer low resistance and high amperage. An FEP dielectric is used to protect the conductors as well as giving the ultimate internal power delivery system.
IsoTek’s internal wiring synergizes with the range of IsoTek power cables. One critical but overlooked area is maintaining commonality of design and material properties though an audio wiring loom, be it signal carrying cables or your power cable network.
進階組件 HIGH GRADE COMPONENTS
IsoTek 每項產品用的都是頂級電子元件，許多都是特製的，並使用高品質金屬材料。品質的追求不僅止於零件，更延伸至印刷電路板（PCB），該設計能維持高電流輸出和超低電阻，使用的銅量高達一般標準的八倍，再加上純銀鍍層。
內部配線則選用高純度銅結合鍍銀工藝，絕緣材料是航太級的氟化乙烯丙烯（FEP）或 IsoTek 獨有的虛擬空氣 介電（VDA）技術，纏繞 FEP 管再加上 FEP 絕緣層，確保了卓越的傳輸表現，打造出低阻抗、高功率的內部供電系統。
Every IsoTek product uses the finest grade electrical components, many custom made, using the highest quality metals and materials which are specifically designed for purpose. Quality doesn’t stop at parts but also extends into the PCB designs, which maintain high levels of amperage and extraordinarily low levels of resistance, using up to eight times the general standard of copper prior to pure silver plating.
Internal wiring also uses high purity coppers combined with silver plating, with either Fluorinated Ethylene Propylene (FEP) dielectric or IsoTek’s Virtual Dielectric of Air (VDA), where a FEP tube is wound around the conductor before an extruded FEP dielectric protects this construction giving unrivalled performance and the ultimate low resistance, high performance internal power delivery system.
SPECIFICATIONS
導體尺寸：3 x 2.0 平方毫米（澳洲 / 紐西蘭 1.5 平方毫米）
CONDUCTOR SIZE：3 x 2.0sqmm (AU/NZ 1.5sqmm)
導體材質：99.9999% 無氧化銅
CONDUCTOR MATERIAL：99.9999% Oxygen Free Copper
絕緣：聚乙烯（PE) （澳洲 / 紐西蘭PVC）
DIELECTRIC：Polyethylen (PE) (AU/NZ PVC)
外層護套：高柔韌性 PVC
OUTER JACKET：High flexibility PVC
安全電流：16A
CABLE POWER RATING：16 Amp
標準長度：1.5m、3m（無客製長度）&System Link 0,5m（澳洲 / 紐西蘭 1.5m）
CABLE LENGTH：1.5m & 3m (no custom length)& System Link 0,5m (AU/NZ 1.5m only)
絕緣係數：PE 2.25（澳洲 / 紐西蘭 PVC 3.18）
DIELECTRIC CONSTANCE：PE 2.25 (AU/NZ PVC 3.18)
填充物：純棉
FILLER：Cotton
PVC 包覆：紙材包覆
PVC BARRIER：Paper wrap
外徑：10mm
OUTER DIAMETER：10mm
電源插頭：發燒級鍍鎳接頭
TERMINATION：Nickel plated audiophile-grade connectors
適用於 CD 播放器、前級 / 後級擴大機、調諧器、藍光機、音樂伺服器、電視、Soundbar、主動式喇叭等！
Suitable for CD players, preamps, tuners, power amps, Blu-ray players, music servers, TVs, soundbars and more!
AVAILABLE INPUTS
AVAILABLE OUTPUTS
DOWNLOADS
PRODUCT VIDEO
價格 PRICE 2024
£99.00（當地售價）
